TP-LINK CPE210 9dbi 300mbps 2.4ghz 10+km Harici Access Point (BIO-97-10062)

0.0

Marka : TP-LINK

Fiyat : ₺2.294,08 + KDV

KDV Dahil : ₺2.752,90

Barkod : 6935364071677

₺688,22 `den başlayan taksitlerle

Adet :

Tavsiye Et

Yorum Yaz

2.4GHz 300Mbps 9dBi Outdoor CPE

Dahili 9dBi 2x2 çift kutuplu yönlü MIMO anteni
0 ila 25dBm / 500mw arasında ayarlanabilir iletim gücü
5 km'den uzun menzilli kablosuz iletim için sistem düzeyinde optimizasyonlar
TP-LINK Pharos MAXtream TDMA (Zaman Bölmeli-Çoklu Erişim) teknolojisi, PTMP uygulamaları için ideal olan üretim, kapasite ve gecikme performansında ürün performansını artırır
Merkezi Yönetim Sistemi - Pharos Kontrolü
AP / Client / AP Router / AP Client Router (WISP) operasyon modları
Pasif PoE Adaptörü, 60 metreye (200 feet) kadar Ethernet dağıtımını destekler ve cihazın uzaktan sıfırlanmasını sağlar

DONANIM ÖZELLİKLERİ
İşlemci	Qualcomm Atheros 560MHz CPU, MIPS 74Kc
Bellek	64MB DDR2 RAM, 8MB Flash
Arabirim	1 10/100Mbps Shielded Ethernet Port (LAN0,Passive PoE in) 1 Grounding Terminal 1 Reset Button
Güç Kaynağı	Passive Power over Ethernet via LAN0 (+4,5pins; -7,8pins) Voltage range: 16-27VDC
Güç Tüketimi	5 Watts Max Note: When deployed using Passive PoE, the power drawn from the power source will be higher by some amount depending on the length of the connecting cable.
Boyutlar ( W X D X H )	224 x 79 x 60 mm
Anten	Built-in 9dBi 2x2 Dual-polarized Directional Antenna Beam Width: 65° (H-Plane) / 40° (E-Plane) Note: For more details, please refer to datasheet
Koruma	15KV ESD Protection 6KV Lightning Protection
Muhafaza	Outdoor ASA stabilized plastic material IPX5 waterproof Certification

KABLOSUZ ÖZELLİKLERİ
Kablosuz Standartlar	IEEE 802.11b/g/n (with Pharos MAXtream disabled)
Tescilli Protokol	TDMA Mode (with Pharos MAXtream enabled)
Kablosuz Hızı	Up to 300Mbps (40MHz,Dynamic) Up to 144.4Mbps (20MHz,Dynamic) Up to 72.2Mbps (10MHz,Dynamic) Up to 36.1Mbps (5MHz,Dynamic)
Frekans	2.4~2.483GHz Note: Available operating frequency may vary depending on the limitations of the countries or regions in which the device is used.
İletim Gücü	25dBm/316mw (Adjustable power by 1dBm) Note: Maximum transmission power may vary across different channels depending on the limitations of the countries or regions in which the device is used.

YAZILIM ÖZELLİKLERİ
Kablosuz Konfigürasyonlar	Pharos MAXtream TDMA Technology 802.11b/g/n Modes Selectable Channel Width: 5/10/20/40MHz Automatic Channel Selection Transmission Power Control Dynamic Frequency Selection (DFS) WDS Enable/Disable Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption, 64/128/152-bit WEP Encryption SSID Broadcast Enable/Disable Multi-SSID with VLAN Tagging (AP mode only) Distance/ACK Timeout Setting Wireless MAC Address Filter Wireless Advanced: > Beacon Interval/RTS Threshold/Fragmentation >Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia
Yönetim	Discovery and Remote Management via Pharos Control application HTTP/HTTPS Web-based management System Log SNMP Agent(v2c) Ping Watch Dog Dynamic DDNS SSH Server
Sistem Araçları	Wireless Signal Quality Indicators: Signal Strength/Noise/Transmit CCQ/CPU/Memory Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP Spectrum Analyzer Speed Test Ping Traceroute
Sistem Düzeyindeki Optimizasyonlar	Optimized IGMP Snooping/Proxy for multicast applications Hardware watch dog

POE ADAPTÖR ÖZELLİKLERİ
Boyutlar (H X W X D)	85.8×43.9×29.7 mm
Arayüzler	1 AC Jack with Earth Ground 1 10/100Mbps Shielded Ethernet Port (Power + Data) 1 10/100Mbps Shielded Ethernet Port (Data)
Buton	Remote Reset Button
Güç Durum LEDleri	Green
Giriş	100-240VAC, 50/60Hz
Çıkış	• V2.0: 24VDC, 0.6A Max • V3.0: 24VDC, 0.5A Max • V3.20: 24VDC, 0.25A Max +4, 5pins; -7, 8pins. (Support up to 60m Power over Ethernet)
Verimlilik	>80%
Sertifikalar	CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark

DİĞERLERİ
Sertifika	CE, FCC, RoHS, IPX5
Paket İçeriği	Outdoor Wireless CPE 24V 0.6A Passive PoE Adapter Pole Mounting Straps AC Power Cord Installation Guide
Sistem Gereksinimleri	Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux. Note: We recommend you to use one of following Web browsers for an improved user experience: Google Chrome, Safari, and Firefox. IE browsers are not recommended.
Ortam	Operating Temperature: -40?~70? (-40?~158?) Storage Temperature: -40?~70? (-40?~158?) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~95% non-condensing
